1.8 Degree Motor NEMA 23 High Power Stepper Motor 57J1880-450 57J1880-450

1 Piece
MOQ
$17.00(1 - 9 Pieces) $15.50(10 - 49 Pieces) $13.50(>=50 Pieces)
Prijs
1.8 Degree Motor NEMA 23 High Power Stepper Motor 57J1880-450 57J1880-450
Kenmerken Galerij Productomschrijving Verzoek om een Citaat
Kenmerken
Specificaties
Model Number: 57J1880-450
Phase: 2
Type: Hybrid
Current / Phase: 5.0A
Current: 5.0A
Step Angel: 1.8
holding torque: 2.2N.m
resistance: 0.4ohms
inductance: 1.8mH
Detent torque: 700gcm
Rotor interia: 520-gcm2
insulation class: B
Lead Wire Number: 4
Weight: 1.15kg
Certificering: ce, ISO, RoHS
Basis informatie
Certificering: ce, ISO, RoHS
Model Number: 57J1880-450
Betalen & Verzenden Algemene voorwaarden
Packaging Details: WHITE BOX
Productomschrijving

1.8 degree motor stepper nema 23 high power stepper motor 57J1880-450

Product Description

Parameter

model step holdingtorque current resis tance inductance detent torque rotor(g-cm2 insulation lead wire weight length
angel(deg) (N.m) /phase(A) /phase(ohms) /phase(mH) (gcm) interia class numbers (kg) (mm)
57J1841-420 1.8 0.7 2 1.4 3.8 220 157 B 4 0.4 41
57J0955-821 0.9 0.9 2.1 1.8 2.5 400 280 B 8 0.6 54
57J1854-828 0.8 0.9 2.8 0.8 1.2 400 280 B 8 0.6 54
57J1876-828 1.8 1.3 2.8 1 2.1 700 460 B 8 1 76
57J1876-447 1.8 2 4.7 0.37 1.75 700 480 B 4 1.05 76
57J1880-450 1.8 2.2 5 0.4 1.8 700 520 B 4 1.15 80
57J1880-830 1.8 2 3 0.7 1.8 700 480 B 8 1.1 80

Dimension

Company Information

Shenzhen Just Motion Control Electromechanics Co .,Ltd .was established with the vision of developing motion control product for the industry .Our company has accumulated several years of experience in this field , integrating research and development, manufacture and marketing. We are always striving to understand the needs of customers, and to develop further in this field.

Our main products are stepper motor drives, step motor, AC servo motor systems, DC brushes and brushless motors and drive systems, multi-axes motion controllers, and intelligent step motors .we also provide complimentary mechanical products, such as motor couplings, gearboxes, and linear motions.
